Dynamic load management & fail-proof OTA software updates

The Device Chronicle spoke to Joel Hermanns, CTO, gridX. gridX is a platform for companies to build modern digital energy products. The gridBox, which is a custom gateway device in the field, and a central cloud application, enables many use cases in digital energy management: EV charging with dynamic load management is just one use case of several. The company works with B2B providers to tailor solutions for them. gridX’s B2B model allows other companies to offer their own products by leveraging the gridX technology such as in home energy management.

Dynamic load management

In this article, we first look at EV charging stations, dynamic load management and how gridX helps address this use case. Joel begins by sharing some of his thoughts on the biggest trends in electrification. He sees this as the massive shift to EV, where major automotive companies are now committing to it. This, he says, will dramatically increase the number of EVs available and the need for increased EV charging infrastructure. Joel believes there is still some distance to travel in terms of building up capacity. He states, “the German Government recently put out some numbers to estimate that by 2030, there will be 10m EVs and 1m chargers available. Currently, there are only about 30,000 chargers available. Each charging station is a massive load and the grid is not built for this purpose necessarily. So this leads to the increased need for the decentralisation of the grid.”

Joel Hermanns CTO gridX
Joel Hermanns, CTO, gridX

EV moves mainstream

Furthermore, EV is now moving from a niche market position to the mainstream mass market.  Vehicle to grid is currently in a trial stage, and Joel adds that as soon as more standards and devices and vehicles are supported, it will be much more interesting. “This is as long as the rest of the technology catches up,” he adds. Energy management systems such as the gridBox also need to be in place on a wider scale to make the energy ecosystem efficient.

Standards helping

Joel also believes that important standards such as OCPP – the protocol for communication for charging stations, billing and control – are gaining more and more traction. “They are needed to manage the complexity and demand that is building up.”

Managing loads

gridX addresses a key problem in EV charging and power management. This is the risk of a power outage from excessive load from charging on a site. Joel explains: if charging stations are placed in facilities or depots, then they add a very high electricity load to the site. He continues “It is not a problem with one charging station, but if you add dozens or 100s of these charging stations in large parking facilities or depots, then the load will increase dramatically. This becomes a problem if all the charging stations are charging vehicles simultaneously.” Furthermore, Joel points out that, “the grid has not been built to support this kind of excessive charging load. You could easily end up having a power black out on the site.”

gridX Solution for dynamic load management

Thankfully there is a solution in dynamic load management where you can limit each charging station to a fraction of what it can do and end up not reaching the problematic load. Usually, not all chargers are used simultaneously, so Joels points out that you can dynamically shift loads from one charger to another. With 10 chargers and only two in use at the same time, you could set two charging stations to charge at full power, while the others are set to zero. This is what is done with the gridBox, which is added locally on-site. With the gridBox gateway device, it is possible to measure what each charging station is consuming and at the same time measure what is going on at the grid connection points. In this way, the consumption of the building can be accommodated by connecting it to site charging consumption. Then, in almost real time all the assets can be managed by shifting energy loads in sub seconds so you can avoid black outs or peaks in usage between the charging EVs and the buildings on site. If dynamic power load management was not in place, the fuse at the grid connection point could blow and all power would be out. To avoid this, in the old scenario Joel explains, you might have to limit all 10 vehicles on the site to 10% charging. Then it would take up to ten times longer to fully charge the cars and this might not be feasible. With the gridBox and dynamic load management, we check the building for the highest and lowest load consumption and then use dynamic load shifting to make more of the available capacity at any given time of the day.

Importance of OTA software updates

Robust and secure OTA software updates provided by are very important for gridX. It helps the company get products for dynamic load management out quickly and evolve them based on customer feedback. Joel explains that the development culture of the company is to ship a very small version first and then iterate quickly. “For such devices distributed over Germany and Europe, we need a system to fix bugs, improve performance and add new software updates. For applications, we have between a weekly and monthly release schedule depending on our partner’s schedule.” is used to provision the system and operating system updates. It is a solid foundation for updating, Joel says. He continues: “the biggest fear when we first launched our products was not being able to update devices. The device OS is so crucial and there is no space for something to go wrong. We didn’t have many experts in the team to handle the complexity of OTA software updates. We were keen to rely on an expert partner that knows more about OTA software updates. This has proved a very wise decision over the last 5 years. Mender has been efficient and worked very well.”

Yocto layer integration

Another great benefit of Mender is the layer integration with Yocto. The Mender engineering team helped set up the hardware in the right way. There are 3 different hardware versions running Mender and it is really easy to maintain with Yocto. The embedded boards are ARM-based: These are low cost but high performance devices. Joel elaborates, “you can imagine connecting to 50 charging stations and you have an algorithm that controls them in sub seconds, then you need a device that is highly performant but at the same time cannot be too expensive. In the consumer market at least, no one is prepared to pay €1000 for a device that does energy management, so this is why the ARM-based devices are so important.” In most situations, the connectivity on the devices is wired, in some cases LTE modems are used with the devices.

Importance of IoT cybersecurity

Joel explains that gridX also pays attention to encryption in transit for all data transmission. Mender has a good setup for authentication of the devices with public keys. It opens the connection from the device to the cloud and not some tunnel that is constantly open. So it minimises the threat vectors to our network.

Handling device scaling

Dozens of devices easily update manually, then you think about device grouping and scheduling updates. Eventually, you reach a point where the groups are too big and then you need to handle the complexity in a different way. Automation is needed as there are so many devices.

Indispensable for OS updates is one of many tools in gridX’s device management setup but is important as a go-to tool for updating the OS. Support has always been great. The documentation and support is excellent for integrating with new devices. We never had problems updating the versions or using the hosted installations. Thanks to, gridX has atomic updates across a large fleet of devices and the Mender system scales with the company, Joel concludes.

We wish Joel and his colleagues at gridX well as they continue their journey in providing valuable digital energy solutions.
